| Specifications | ||
|---|---|---|
| Platform | Intel®
Centrino® processor
technology - Intel® Core™ Duo Processor U2500 (1.20GHz ULV, 2MB L2 cache, 533MHz FSB) - Intel® PRO/Wireless 3945ABG/3945BG network connection - Intel® 945GMS Express Chipset |
|
| Operating System |
Genuine
Windows Vista® Business (or Genuine Windows Vista® Home Premium) |
|
| Display | 10.6-inch SuperFine Wide XGA TFT, 1280 x 768 pixels | |
| Modular Bay Device | Dual Layer DVD Super Multi Writer5 | |
| Memory | 1GB DDR2 667MHz11 Max. Memory Supported : 2GB DDR2 667MHz11 |
|
| Hard Disk | 80GB | |
| Bluetooth® | v2.0 + EDR (Enhanced Data Rate) | |
| Battery | Up to 5.9hrs12 (6-cell Li-Ion, 10.8V, 5800mAh) | |
| Weight | Approx. 1.19kg (w/ weight saver option) | |
| Detailed Specifications | ||
| Hard Disk Drive | PATA 4200rpm, S.M.A.R.T support, Two Partitions - 50/508, protected by Fujitsu 3D Shock Sensor9 | |
| Graphics | Integrated Intel® Graphics Media Accelerator 950 with DVMT7 3.0 delivers low-power, high-performance 2D/3D graphics, video and display capabilities at a maximum shared memory of 224MB | |
| High Definition (HD) Audio | STAC9228 Controller
Chip with dual built-in stereo
speakers HD Audio-in: External Mic-in, Dual Digital Array Built-in Microphones HD Audio-out: Headphone-out |
|
| 3.5G13,15 | Embeded 3.5G (HSDPA)
WWAN connectivity with dual Antenna.
Up to 3.6 Mbps14
downlink - Supports tri-band UMTS (HSDPA): 850, 1900, and 2100 MHz - Supports quadband EDGE/GPRS/GSM: 850/900/1800/1900 MHz |
|
| Communication | Bluetooth® v2.0 + EDR, 56K V.921 Global Modem13 MDC1.5, 1000/100/10Mbps2 Gigabit Ethernet PCI Express x 1 and Intel® PRO/Wireless 3945ABG/3945BG network connection. Separate ON/OFF switch for wireless network connection, Integrated Camera 1.3 Mega Pixels. Integrated 3.5G13 | |
| User Interface | Keyboard: 82-key,
18mm key pitch, 2mm key stroke Intelligent Touch Pad with configurable vertical and horizontal scroll functions Fingerprint sensor with vertical scroll functions |
|
| Card Slot | PCMCIA Type I/II, SD/MS/xD, Smartcard support3 | |
| Connector Interface | USB 2.0 x 2, VGA (external display), RJ45 (LAN), RJ1113 (modem), IEEE1394, Audio-in, Audio-out, Power Adapter DC-in, Port Replicator Interface | |
| Quick Launch Panel | One Programmable Application Launch Button, ECO (Power saving) button | |
| Security 4 | BIOS Lock,2-password Hard Disk Lock, Anti-theft Lock Slot, Fingerprint Sensor | |
| Dimensions | 272.9mm (W) x 200.9mm (D) x 27.1-29.9mm (H) | |
| Bundled Accessories | ||
| AC Adapter | Input AC 100~240V, Output DC 16V 60W | |
| Bundled Software | Softex OmniPass, CyberLink PowerDVD™, CyberLink PowerProducer™, Roxio Easy Media Creator, Adobe Acrobat Reader, Fujitsu UpdateNavi10, Fujitsu Hardware Diagnostic Tool, Fujitsu Display Manager, Microsoft Office Professional 2007 60-day Convertible Trial16 | |
| Software on CD | Acronis True Image, 1 year Full Licensed Norman Virus Control with Sandbox Technology and Norman Personal Firewall | |
| Optional Accessories | ||
| Modular Bay Options | Replaceable with - Bay Battery, 6-cell Li-Ion 2300mAh, up to 9.0hrs12 battery life (Standard + Bay Batteries) - Dual Layer DVD Super Multi Writer (lightweight)5 - DVD/CD-RW Combo drive - Weight Saver |
|
| Port Replicator | Connector Interface:
USB 2.0 x 3, S Video-out, Line-out, VGA (external display), RJ45 (LAN), Power Adapter DC-in |
|
| Mouse | Optical USB Black Mouse (Retractable) | |
The above information shows the general
technical specifications of the product and does not
represent actual configuration that would be sold in
your region. For specific configurations and their
availability, please check with your
local distributors.
1. Maximum 56Kbps performance varies according to
your local service providers' services as well as
line condition. V.92 performance is dependent on
local service providers' services.
2. This term does not represent actual data rate of
1000/100/10Mbps and simply indicates compliance with
IEEE 802.3, IEEE 802.3u and IEEE 802.3ab standards.
Actual maximum data rate depends on network
configurations, cable conditions as well as
connected devices.
3. Fujitsu does not provide the application for
Smartcard solution.
4. BIOS Lock needs a supervisor/user password to
access BIOS setup. BIOS settings can be configured
to prompt for password at every first bootup or all
bootup sequences. Access to BIOS setup is needed to
configure Hard Disk Lock. Hard Disk Lock requires an
access key to retrieve data on the hard disk. This
is a Data Confidentiality security feature.
Anti-theft Lock Slot allows the use of a lock to
physically secure the LifeBook. Smartcard slot usage
is dependent on customer's solution. Fingerprint
sensor uses AuthenTec TruePrint™ Technology and
Softex OmniPass to remember customer list of user
IDs and passwords. Full security unlock sequence -
Bootup Lock (BIOS Lock), Hard Disk Lock, Fingerprint
Windows Logon.
NOTE: Loss of password requires the LifeBook to be returned to Japan factory for system refresh. Cost of shipment and lost data will be borne by the customer. Backup your user's profile before changing HDD. Without the user's profile associated with a document at the point of encryption, Softex OmniPass cannot decrypt the encrypted document. 2 passwords refers to Master Password and User Password of the HDD Lock. The Master Password can be used to clear the User Password at the BIOS settings under Hard Disk Security. If HDD Lock prompt is enabled, only the User Password can be used to boot up the unit. Loss of these 2 passwords means the HDD content cannot be retrieved. It is the customer's responsibility to ensure the safe keeping of these 2 passwords for retrieval of data from the locked HDD.
NOTE: Loss of password requires the LifeBook to be returned to Japan factory for system refresh. Cost of shipment and lost data will be borne by the customer. Backup your user's profile before changing HDD. Without the user's profile associated with a document at the point of encryption, Softex OmniPass cannot decrypt the encrypted document. 2 passwords refers to Master Password and User Password of the HDD Lock. The Master Password can be used to clear the User Password at the BIOS settings under Hard Disk Security. If HDD Lock prompt is enabled, only the User Password can be used to boot up the unit. Loss of these 2 passwords means the HDD content cannot be retrieved. It is the customer's responsibility to ensure the safe keeping of these 2 passwords for retrieval of data from the locked HDD.
5. Supports DVD multi formats such as DVD-RAM, DL
DVD±R, DVD±RW, DVD±R, CD-RW, DVD-ROM, CD-R and
CD-ROM.
6. RoHS (Restriction on Hazardous Substances)
compliance means the system and its internal
components comply with the EU RoHS directive
(2002/95/EC) on the restricted use of six hazardous
substances in the production of the system and its
internal components
7. Dynamic Video Memory Technology (DVMT)
dynamically responds to application requirement and
efficiently allocates the proper amount of memory
(max.224MB) for optimal graphics and system
performance. The memory size available to the
Operating System will be less than the size of
installed memory module.
8. This refers to Windows Vista® hard disk drives
C:\ and D:\ . 50/50 refer to approximate 50%
allocation of user accessible hard disk storage to
C:\ and D:\ drives. For Windows Vista® hard disk
drives, 1GB will be reserved for internal recovery
usage which is not shown.
9. Fujitsu 3D Shock Sensor of a powered-up unit
retracts hard disk read-write head to a secured zone
upon detection of excessive vibrations or shocks.
This greatly reduces the possibility of damage to
the hard disk and its content - example in the event
of a sudden drop or impact. The sensor monitors
movement from three axes and its sensivity can be
adjusted by user to accommodate different working
environments using the Fujitsu 3D Shock Sensor
Utility.
10. UpdateNavi is a Fujitsu Proprietary application
that updates LifeBook drivers by connecting
automatically to Fujitsu’s server. This will help
update your LifeBook with the latest software
drivers and utilities to ensure compatibility
between hardware and software, maintaining smooth
operation anytime, anywhere.
11. P7230's Front Side Bus(FSB) is 533 MHz. When
using the DDR2 667MHz memory module, the system will
automatically step it down to 533 MHz.
12. Results obtained from BAPCO MobileMark2005
(Productivity Workload 2002SE) performed on systems
with maximum battery life settings under laboratory
testing environment. Actual battery life will vary
based on screen brightness, sound volume settings,
running applications, connected peripherals, power
management settings, battery conditioning, and other
customer preferences in the real life situation.
Modular bay devices or hard drive usage may also
have a significant impact on battery life. Note: Up
to 5.9hrs battery life is based on Intel® Core™ Duo
Processor U2500 configuration with 6-cell 5800mAh
standard battery. Up to 9.0hrs battery life is based
on Intel® Core ™ Duo Processor U2500 configuration
with 6-cell 5800mAh standard battery and 6-cell
2300mAh bay battery.
13. Please check with your local distributors on the
availability of the 3.5G model. Note: For 3.5G
model, modem will not be installed. They are
exclusive of each other.
14. Subject to network and SIM capabiltiies. Data
rates refers to download or upload speed which is
also dependent on network capabilities and
conditions.
15. 3.5G module comes with a 1 year local carry-in
warranty.
16. Microsoft Office Professional 2007 60-day
Convertible Trial needs online activation to begin.
60-day starts from day of activation.
